TADANO ATF40G-2

All terrain cranes

Max. Lifting Capacity : Boom 40t x 2.5m
Max. Lifting Height : Boom 35.5m
Max. Lifting Height : BoomJib 45.0m
Max. Load Radius : Boom 32.0m
Max. Load Radius :  Boom+Jib 38.0m
Boom Length : 10.45m – 35.2m

FEATURE & BENEFITS

A POWERFUL YET COMPACT TWO-AXLE CRANE

The ATF 40G-2 is a powerful yet compact two-axle crane that is quick to deploy in a wide range of applications. Tasks such as rigging other cranes and lifting smaller objects are its main applications. Reliable, flexible and economical, the AFT 40G-2 can be driven on-road in its 12 t axle load configuration with a 1.4 t counterweight, 445/95 R 25 tires and 9.0 m boom extension.

Product Specifications

Crane

Max. Lifting Capacity (Boom) 40t x 2.5m
Max. Lifting Height (Boom) 35.5m
Max. Lifting Height (Boom+Jib) 45.0m
Max. Load Radius (Boom) 32.0m
Max. Load Radius (Boom+Jib) 38.0m
Boom Length 10.45m – 35.2m

Carrier

Engine Model Mercedes Benz (Euromot III B, EPA Tier 4i)
Max. Output (Carrier) 205 kW (279 HP)
Max Traveling Speed 85km/h
Drive/Steering 4 x 4 x 4
Overall Length 11,031mm
Overall Width 2,550mm.
Overall Height/td> 3,551mm
